Description
BOYA WM8 Pro er opgraderet version af UHF Dual-Channel Wireless Microphone System og
kan bruges til at optage lyd til live lyd, ENG, transmission og film, talkshows, konferencer og mere.
BOYA WM8 Pro-K2-systemet består af:
1 styk dobbelt kamera-monterbar modtager
2 styk bodypack-sendere
2 styk omnidirektionelle (kuglekarakteristik) lavalier-mikrofoner med clips og vindhætte
1 styk kamerasko monteringsadapter
1 styk minijack til XLR kabel
1 styk minijack til minijack kabel.
Leveres samlet i transport kuffert
Kamera modtageren har et bredt RF-båndbredde, et let at læseligt LCD-display
og en 3,5 mm hovedtelefonstik til realtidsovervågning. Bodypack-senderen er udstyret
med en krystalkontrolleret PLL-synthesizer, en muting-funktion, minijack mic input og minijack line-in.
Product Highlights:
Dual-Channel Wireless Receiver
Consists of One Transmitter and One Receiver
UHF transmission with 48UHF channels
Ideal for ENG/EFP, DSLR Video
Broadcast-Quality Sound
Operation range can reach up to 100m
Adjustable MONO and Stereo mode
Powered by one 2 x AA batteries for both transmitter and receiver
Oscillator type: PLL Synthesized Control Oscillator
Carrier Frequency Range: 576.4 MHz-599.9 MHz (Transmitter: A ), 568.6 MHz-592.1 MHz (Transmitter: B )
Channels:48
Frequency response: 40 Hz to 18 kHz (+/-3dB)
Operation range: 100m (300′)(without obstacle)
Operating temperature: 14° F to 122° F (-10° C;to +50° C)
Storage temperature: 14° F to 131° F (-10° Cto +55° C)
Transmitter:
RF output power: 10 mW
Antenna: 1/4″ wire antenna
Spurious emission: 250 nW or less
Audio input connector: 3.5mm mini jack
Reference audio input level:-60 dBV (MIC input, 0 dB attenuation)
Reference deviation: ±5 kHz (-60 dBV, 1 kHz input)
Input frequency range: 20 Hz-20 KHz Distortion: 0.5% or less
Power supply: Two AA size batteries Operation time: About 6 hours
Dimensions: 208(H)× 67(W) × 29(L)mm
Weight: 80g without batteries
Receiver:
Antenna: 1/4″ wire antenna
Audio input connector: 3.5mm mini jack
Signal-to-noise ratio: 70 dB or more
Distortion: 0.5% or less
Headphone output level:30mW (16 Ohm)
Audio output level: -60 dBV
Power supply: Two AA size batteries
Operation time: About 4 hours
Dimensions: 208(H) × 67(W) × 29(L)mm
Weight: 90g without batteries
Lavalier Microphone:
Transducer: Back electret Condenser
Polar pattern: Omni-directional
Frequency Range: 35Hz ~ 18 KHz
Signal / Noise: 74dB SPL
Sensitivity:-30dB +/-3dB / 0dB=1V/Pa, 1 kHz
Connector: 3.5mm locking mini plug Length: 1.2m
